android ListView 的使用

1. main .xml 配置文件



<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:orientation="vertical" >

    <LinearLayout
        android:id="@+id/lausb"
        android:orientation="vertical"
        android:layout_height="wrap_content"
        android:layout_width="wrap_content">
        <ListView
            android:id="@android:id/list"
            android:layout_width="fill_parent"
            android:layout_height="wrap_content"
            android:drawSelectorOnTop="false"
            android:scrollbars="vertical"
            ></ListView>
    </LinearLayout>

</LinearLayout>





2. user.xml 配置文件

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:orientation="horizontal" >
    <TextView
           android:id="@+id/title"
           android:layout_width="wrap_content"
           android:layout_height="fill_parent"
           android:textSize="22px"
           android:width="100px"
            />
    <TextView
       android:id="@+id/info"
       android:layout_width="wrap_content"
       android:layout_height="fill_parent"
        />
</LinearLayout>



3. java 类文件



package com.listview;

import java.util.ArrayList;
import java.util.HashMap;
import java.util.Map;

import android.app.ListActivity;
import android.os.Bundle;
import android.view.View;
import android.widget.ListView;
import android.widget.SimpleAdapter;


/**
 *
 * @author liuqing
 * @version 1.0
 * @see Android ListView 的使用
 * 2011-10-12
 *
 */
public class ListViewActius extends ListActivity {

	@Override
	protected void onCreate(Bundle savedInstanceState) {
		// TODO Auto-generated method stub
		super.onCreate(savedInstanceState);
		setContentView(R.layout.main);
		ArrayList<Map<String,String>> list = new ArrayList<Map<String,String>>();
		Map<String,String> map1 = new HashMap<String,String>();
		Map<String,String> map2 = new HashMap<String,String>();
		Map<String,String> map3 = new HashMap<String,String>();
		map1.put("title", "liuqing");
		map1.put("info", "192.168.0.105");

		map2.put("title", "qing");
		map2.put("info", "192.168.32");

		map3.put("title", "haha");
		map3.put("info", "192.168.0.22");
		list.add(map1);
		list.add(map2);
		list.add(map3);

		SimpleAdapter listAdapter = new SimpleAdapter(
				this,
				list,R.layout.user,
				new String[]{"title","info"},
				new int[]{R.id.title,R.id.info});
		setListAdapter(listAdapter);

	}

	@Override
	protected void onListItemClick(ListView l, View v, int position, long id) {
		super.onListItemClick(l, v, position, id);
		System.out.println(" position:" + position + "===id: " + id);
	}





}
