Android 之VideoView播放rtsp格式数据

效果图片:


AndroidManifest.xml:

<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
    package="com.iaiai.activity"
    android:versionCode="1"
    android:versionName="1.0" >

    <uses-sdk android:minSdkVersion="8" />

    <application
        android:icon="@drawable/ic_launcher"
        android:label="@string/app_name" >
        <activity
            android:name=".MainActivity"
            android:configChanges="orientation|keyboardHidden|navigation"
            android:label="@string/app_name" >
            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>
    </application>

</manifest>

main.xml:

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:orientation="vertical" >

    <VideoView
        android:id="@+id/VideoViewDisplay"
        android:layout_width="fill_parent"
        android:layout_height="fill_parent" android:layout_gravity="center"  />

</LinearLayout>

MainActivity.java

package com.iaiai.activity;

import android.app.Activity;
import android.app.ProgressDialog;
import android.content.pm.ActivityInfo;
import android.media.MediaPlayer;
import android.media.MediaPlayer.OnPreparedListener;
import android.os.Bundle;
import android.util.Log;
import android.view.Window;
import android.view.WindowManager;
import android.widget.MediaController;
import android.widget.VideoView;

public class MainActivity extends Activity {

	private VideoView mVideoView;

	private ProgressDialog loadingDialog; // loading

	@Override
	public void onCreate(Bundle savedInstanceState) {
		requestWindowFeature(Window.FEATURE_NO_TITLE);
		super.onCreate(savedInstanceState);
		setContentView(R.layout.main);

		getWindow().setFlags(WindowManager.LayoutParams.FLAG_FULLSCREEN,
				WindowManager.LayoutParams.FLAG_FULLSCREEN);
		setRequestedOrientation(ActivityInfo.SCREEN_ORIENTATION_LANDSCAPE);

		loadingDialog = new ProgressDialog(this);
		loadingDialog.setMessage("Loading...");
		loadingDialog.show();
		// loadingDialog.setCancelable(false);

		mVideoView = (VideoView) findViewById(R.id.VideoViewDisplay);

		final MediaController controll = new MediaController(MainActivity.this);
		controll.setMediaPlayer(mVideoView);
		mVideoView.setOnPreparedListener(new OnPreparedListener() {
			@Override
			public void onPrepared(MediaPlayer mp) {
				Log.i("************", "注册在媒体文件播放完毕时调用的回调函数。");
				loadingDialog.dismiss();
			}
		});
		mVideoView
				.setVideoPath("rtsp://218.205.231.149:554/live/1/35AB46A109903442/0037f42790b7cb14.sdp?id=guest&t=1305311828&en=a4d5d7adaf0eca0d907875009a901a85&rs=wap");
		mVideoView.setMediaController(controll);
		mVideoView.requestFocus();
		mVideoView.start();
		controll.show();
	}

}
